Layflat Drinking Water Hose

Layflat drinking water hose is a flexible layflat pipeline designed for emergency and temporary drinking water delivery operations with high working pressures.It is light-weight and abrasion resistance suitable for long distance water transportation. It can be deployed more quickly and safely compare to rigid pipe.

Layflat Drinking Water Hose

Construction

Cover and liner: High quality food grade TPU

Reinforcement: High tenacity synthetic yarn

Technical Parameters

Color: light green or as required

Size: 2 inch-12 inch

Length: 200m(660ft) or as required

Temperature: -50°C～+80°C(-60°F to 176°F )

Features

High abrasion and kink resistance, high pressure, UV resistance, high flow, safe and quick installation, long life time

Application

Emergency potable water supply, water bypass, army and ship drinking water supply

Production Process

Specification

Size		Working Pressure		Burst Pressure		Wall Thickness	Length
Inch	mm	Bar	Psi	Bar	Psi	mm	m/ft
2	51+1.5	17	250	51	750	2	200/660
3	76+2.0	17	250	51	750	2.5
4	103+2.0	17	250	51	750	2.8
6	154+2.5	14	200	42	600	3.4
8	204+3.0	14	200	42	600	4.3
10	254+3.0	14	200	42	600	4.6
12	305+3.0	10	150	30	450	4.7

Size, working pressure and wall thickness can be customized as required.
